08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

Brand Name : TORICH

Model Number : 08X17H13M2T 316Ti

Certification : ISO,SGS,Other,ROHS

Place of Origin : Zhejiang/China

MOQ : 1Ton

Price : Negotiable

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability : 60000 Ton/Tons per Year

Delivery Time : 20-30days upon products

Packaging Details : In bundles or in wooden boxes.

Steel grade : 300 Series,200 Series,400 series,TP316,200/300 series

Application : High temperature service

Type : seamless and welded,round

Welding line type : ERW,Seamless,Spiral Welded,TIG

Standard : GB,ASTM,DIN,AISI,JIS

Thickness : 0.5-100mm,

Outer diameter : 6-760mm

Length : 1m-12m,6m or as customers' request,30mm or custom,0-12m,2.5-8m

Product name : Stainless Steel Tubing,Fast Sell square stainless steel pipe price per ton

Surface : BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D

Material : 200 Series/300 Series/400series,200,202,AISI 201,400 series

Shape : square,Round.square.Rectangle,

Finish : Brush Polish,hairline,BA,mirror ETC,pickled

Technique : Cold Rolled Hot Rolled,Cold Drawing

Grade : 201/202/304 /304L/316/316L321/310s/410/420/430/440/439ect,201,316L,202,304L 316 316L 310s 321 321H 347 347H

Name : Seamless Stainless Steel Tubing,stainless steel telescopic tube,Stainless Steel Circular Corrugated Water Pipe

Secondary Or Not : Non-secondary

Usage : For Fluid Transport

Process : hot-rolling

Test : Extended test, Water pressure test,

Processing Service : Punching, Cutting

Sample : Sample Freely

Specification : Customized

Contact Now

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

Material

08X17H13M2T is a Russian designation for a titanium-stabilized austenitic , equal to 316Ti grade. it's miles designed to be used in excessive-temperature environments in which corrosion resistance and mechanical sturdiness are essential.

Specification

  • Elegant: GOST 9941-80 one, ASTM A213, A312 / EN 1.4571 / JIS SUS 316Ti
    Shape: spherical tube/pipe
    Size: Outer diameter and wall thickness as in step with requirement, normally beginning from 6mm to 630mm diameter, with numerous wall thicknesses.
    Duration: typically furnished in random or steady lengths in step with patron specifications
    Floor Stop: Pickling, polished, or as requested

Key Features

  • incredible corrosion resistance in oxidizing and mildly lowering atmospheres
    immoderate resistance to intergranular corrosion due to titanium stabilization
    nicely mechanical houses at improved temperatures (as much as 870°C)
    robust resistance to pitting and crevice corrosion in chloride environments
    applicable weldability and formability
    lengthy issuer lifestyles in immoderate temperature and stress programs

Chemical Composition

Element C Si Mn P S Cr Ni Mo Ti N Fe
% ≤0.08 ≤1.00 ≤2.00 ≤0.035 ≤0.03 16.00-18.00 10.00-14.00 2.00-3.00 5×C min to 0.70 ≤0.10 Balance

Mechanical Properties

Property Value
Tensile Strength (σb) ≥520 MPa
Yield Strength (σ0.2) ≥210 MPa
Elongation (δ5) ≥40%
Hardness (HB) ≤200
Impact Toughness (ISO-V) ≥40 J (at room temperature)
Operating Temperature Range Up to 870°C

Equivalent Grades

Country/Standard Grade
ASTM A182 F316Ti, A213 TP316Ti
EN 1.4571
GOST 08X17H13M2T
JIS SUS 316Ti
GB (China) 0Cr17Ni12Mo2Ti

Application

  • warm temperature exchangers and boilers strolling beneath excessive temperatures
    Chemical processing system uncovered to corrosive media
    Furnace additives and excessive-temperature piping systems
    Petrochemical corporation piping and system
    Offshore structures and marine packages at risk of chloride-triggered corrosion
    meals processing device in which corrosion resistance is critical
    power plants and superheater tubes

This specialised 08X17H13M2T (316Ti) is exceedingly suitable for environments requiring sustained mechanical power and corrosion resistance at multiplied temperatures, making it a dependable choice for business programs disturbing sturdiness and safety.


08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature


08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature 08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature


08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature


TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.

The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.

The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.

Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

08X17H13M2T Round Stainless Steel Tube 316Ti Stainless Steel Pipe For High Temperature

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.


Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.


Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.


Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
